Active Speaker 2 x 5″/Dome Tweeter 160W digipack
A powerful yet surprisingly light cabinet, the remarkably compact L160D offers a variety of connection options to provide convenient sound reinforcement for multimedia applications.
Paired with a DSP, the two 5“ phase-corrected loudspeakers deliver astonishingly high sound pressure levels for their size and an amazingly transparent and articulate sonic image. The multifunctional housing offers wall-mount fixing points for permanent installation and a pole mount for portable use.

Technical data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 70 – 20.000 Hz
Max SPL: 116 dB
HF: 1 “
Type HF: Dome Tweeter, coaxial
Directivity: 85 x 75 °
LF: 2x 5 “
Amplifier
Amp Technology: digipro
Amp Class: Class D
HF Amp: 40 W/RMS
LF Amp: 120 W/RMS
Cooling: Convection
Processor
Controller: DSP 24bit/48kHz
System Presets: 8 Presets; Live; Playback; Stage Monitor; Male; Female; Studio Monitor; Autoloudness; L160 analog
Limiter: Dual Active
Peak, RMS, Thermal
Slope MF-HF: 24 dB/Octave
Input Section
Signal Input: 1x XLR Line In/Mic
1x 6.3mm phone jack
1x RCA cinch AUX with volume control
Microphone Input: Yes
Signal Output: 1x 6.3mm phone jack
Power Socket: VDE
Voltage Range: 110-120 – 220-240 V
Mechanics
Housing: Polyporpylen PP
Housing Design: Multifunctional
Colour: Black
Handles: 1x on back (slot)
Pole Mount: Optional accessories
Tilt Unit: Optional accessories
Angles Up: 60° for monitor use °
Front Grille: Metal, 1mm
Rigging Points: 2x M5 on side
2x M5 on bottom
for accessories
Width: 200 mm (8 in)
Height: 335 mm (13.4 in)
Depth: 220 mm (8.8 in)
Weight: 5.2 kg (11.46 lbs)
