2 Way Passive Speaker
Born as an evolution of wooden LVX active series, the new LVX P family moves into the installation world with a passive selection of cabinets where a clean, essential design merges with a very detailed and coherent audio performance.
LVX P cabinets are equipped with premium components and are designed to render speech, live or background music in medium to large venues delivering a clear, detailed audio performance.
Full range LVX P15 provides a 90°x60° dispersion pattern and is equipped with a rotatable horn to guarantee the same HF coverage even in case of horizontal install.
The solid plywood enclosures features a clean, install-friendly design featuring 12 M8-thread rigging points to ease installation with dedicated horizontal (WB-LP15H or vertical brackets (VB-LP1215V).
The cabinet features 1 integrated handle per side and a 36 mm pole mount plate.
All enclosures and accessories of LVX P series are available in black or white version.

2-way passive speaker
Clean design
Available in black or white
M8-thread rigging points
Rotatable horn for vertical or horizontal use
Wooden lightweight enclosure

Technical Data
Speaker Type: 2-Way Passive Speaker
Acoustical Data
Peak Power: 800 W
Impedance: 8 Ohms
Frequency Response [- 10 dB]: 58 – 21.000 Hz
Max SPL: 129 dB
HF: 1 “, 1.35″ v.c.
Directivity: 90×60 °
Horn: Rotatable
LF: 15“, 2.5″ v.c.
Input
Signal Input: 1x Speakon (Pin 1+=+) (Pin 1-=-)
Signal Output: 1x Speakon (Pin 1+=+) (Pin 1-=-)
Mechanics
Housing: Plywood
Pole Mount: 36 mm
Angle Up: Monitor use 40°
Rigging Points: 12 x M8
Handles: 2 (1 per side)
Width: 420 mm
Height: 680 mm
Depth: 430 mm
Weight: 19.7 kg
Note: Data is not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
